Product Description
All the power of a 20-ton gas wood splitter — without the gas, the fumes, or the maintenance. The Ram Splitters HV20-4 is a 20-ton electric horizontal and vertical log splitter built in the USA that plugs straight into your existing 110V outlet and gets to work immediately.
The question customers always ask is — does electric mean less power? Not here. The high-torque 2HP Leeson electric motor delivers the same splitting force as the gas-powered 20-ton version of this exact machine. In fact, if you ever decide to switch to a gas motor down the road, you can — just swap out the motors. Same machine, different power source.
Split horizontally for standard firewood on the beam, or switch to vertical and slide large rounds into position without lifting them. The 4 x 24-inch cylinder handles logs up to 26 inches in the opening with 20 tons of force behind every stroke. The 29-inch working height keeps you comfortable through the whole session, and the 2-spool auto-return valve keeps the cycle smooth and consistent at 15 to 17 seconds.
Built in the USA, road towable with a 2-inch coupler and safety chains, and fully customizable with optional 4-way wedge and log cradles. Just plug into a 25-amp dedicated circuit breaker and start splitting.
Ideal For: Homeowners, hobby farmers, small property owners, and anyone who heats with wood and wants a powerful, low-maintenance electric wood splitter with horizontal and vertical capability — without ever buying gas again.
Key Features
▪ 2HP Leeson Electric Motor — Same splitting power as the gas-powered 20-ton version — high torque, no gas, no fumes, no maintenance
▪ Swappable Motor Design — Want to switch to gas later? Just swap the motor — same machine, different power source
▪ 20-Ton Splitting Force — 40,000 lbs of hydraulic force handles dense hardwood and large diameter logs without hesitation
▪ Horizontal & Vertical Operation — Split on the beam or slide large rounds into the vertical position without lifting them
▪ Made in the USA — Designed and built in the USA to professional quality standards
▪ Road Towable — 2-inch coupler and safety chains — tow it anywhere at highway-compatible speeds
▪ 15-17 Second Cycle Time — Consistent, reliable cycle for residential and small-scale firewood production
▪ 26-Inch Log Opening — Handles logs up to 26 inches in the opening for a wide range of firewood sizes
▪ 29-Inch Working Height — Ergonomic height keeps you comfortable and off your knees through long splitting sessions
▪ 11 GPM Two-Stage Pump with Auto-Return Valve — Smooth, consistent hydraulic performance on every stroke
▪ Optional 4-Way Wedge — Splits logs into 4 pieces per pass — slips over existing wedge quickly and easily
▪ Optional Log Cradles — Catches falling split wood so you spend less time bending over picking pieces up off the ground
Technical Specifications
| Specification |
Detail |
| Splitting Force |
20 Ton (40,000 lbs) |
| Cylinder |
4 x 24 in. |
| Cycle Time |
15–17 Seconds |
| Log Opening |
26 in. |
| Operation |
Horizontal & Vertical |
| Wedge Height |
8 in. |
| Beam Structure |
2 x 5 in. Tubular, 5 in. Top Plate |
| Working Height |
29 in. |
| Motor |
2HP Leeson Electric |
| Power Requirement |
110VAC, 25 Amp Dedicated Circuit |
| Hydraulic Pump |
11 GPM Two-Stage |
| Safety Control Valve |
Detent, Auto-Return |
| Hydraulic Tank |
5 Gallons |
| Tires |
High-Speed 4.80 x 8 |
| Hitch |
2 in. Coupler & Safety Chains |
| Road Towable |
Yes |
| Operating Size |
50 x 84 in. horizontal, 54 in. vertical |
| Operating Weight |
450 lbs. |
| Origin |
Made in USA |
What's Included
▪ Ram Splitters HV20-4 Electric Log Splitter (fully assembled) ▪ 2-inch coupler and safety chains ▪ Operator Manual
Note: 4-way wedge and log cradles are available as optional add-ons. Hydraulic fluid not included.
Done buying gas and dealing with engine maintenance? The Ram Splitters HV20-4 delivers 20-ton splitting force from a standard outlet — USA-made, road towable, and backed by a free 1-year parts and labour warranty. Add it to your equipment today.
