Product Description

Twenty tons of splitting force, a Honda GC160 5.5 HP engine, and the flexibility to split both horizontally and vertically — the Ram Splitters HV20-3 is a practical, reliable wood splitter built for the homeowner or property owner who splits firewood regularly and wants a machine that handles the full range of log sizes without breaking a sweat.

Work horizontally at a comfortable 32-inch waist height for standard firewood logs, or switch to vertical and roll large heavy rounds into position without lifting them onto the beam — your back will thank you by the end of the day. The Honda GC160 OHV engine delivers efficient, consistent power through a 2-stage 11 GPM hydraulic pump with a 13-second auto-return cycle — smooth and reliable from the first split to the last.

The complete tow package with highway-rated tires, safety chains, and 2-inch hitch coupler means this splitter is road towable up to 35 MPH — take it to the woodlot, a neighbor's property, or wherever the work is. At 425 lbs it is solid enough to stay stable during splitting and manageable enough to move when needed.

Please note: this product is not for sale in California.

Ideal For: Homeowners, hobby farmers, and property owners who split firewood regularly and need a dependable horizontal and vertical wood splitter with Honda reliability, road towable capability, and 20-ton force at an accessible price point.

Key Features

▪ 20-Ton Splitting Force — Powers through logs up to 40 inches in diameter including dense hardwood and large rounds

▪ Honda GC160 OHV Engine — 160CC Honda engine with OHV design for increased efficiency and optimal power transfer

▪ Horizontal & Vertical Operation — Split standard logs at waist height or roll large rounds into the vertical position without lifting

▪ 13-Second Cycle Time with Auto-Return — Smooth, consistent 2-stage 11 GPM hydraulic pump cycle from the first split to the last

▪ Road Towable at 35 MPH — Highway-rated tires with safety chains and 2-inch hitch coupler — take it anywhere the work is

▪ 32-Inch Beam Working Height — Ergonomic waist-height splitting reduces back strain through long sessions

▪ Hardened Steel Wedge — 8-inch wedge delivers clean, consistent splits on every stroke

▪ Tube Steel Beam Construction — Durable beam built for reliable daily splitting use

▪ Tongue Stand Included — Easy setup and stable positioning on any flat surface

▪ Compact & Manageable — At 425 lbs and 72 x 40 x 48 inches — solid during splitting and movable when needed

Technical Specifications

Specification Detail
Model HV20-3
Ram Force 20 Ton
Stroke 24 in.
Cycle Time 13 Seconds
Max Log Length 25 in.
Max Log Diameter 40 in.
Wedge Single Hardened Steel
Wedge Height 8 in.
Beam Type Tube Steel
Beam Working Height 32 in.
Engine Honda GC160, 5.5HP, 160CC
Engine Type OHV
Hydraulic Pump 11 GPM Two-Stage
Hydraulic Valve Detent Valve
Hydraulic Tank 5 Gallons
Cylinder Welded 4 x 24 in. with 2.5 in. Rod
Hoses Wire Hydraulic
Trailer Hitch 2 in. Coupler with Safety Chains
Max Tow Speed 35 MPH
Assembled Dimensions 72 x 40 x 48 in.
Product Weight 425 lbs
CARB Approved No — Not for Sale in California

What's Included

▪ Ram Splitters HV20-3 Log Splitter (fully assembled) ▪ Safety chains ▪ 2-inch hitch coupler ▪ Operator Manual

Need a dependable 20-ton horizontal and vertical wood splitter with Honda reliability and road towable capability? The Ram Splitters HV20-3 handles the full range of firewood logs at a price that makes sense — backed by a free 1-year parts and labour warranty. Add it to your equipment today.

Warranty

This product is backed by a free 1-year parts and labour warranty through Ram Splitters
